DAYTON

Exhaust Ventilator 24 In 208-230/460 V

Sold out
  • Exhaust Ventilator 24 In 208-230/460 V

DAYTON

Exhaust Ventilator 24 In 208-230/460 V

Sold out
Mfr Model #: 6KWN9
WEI Part #: 6KWN9
Contract  51V : Catalog - 332510C

Direct Drive Axial Exhaust Ventilator Propeller Dia 24 In. CFM @ 0.000-In. SP 6042 Sones @ 0.125-In. SP @ 5 ft 21 Sones @ 0.250-In. SP @ 5 ft 20 Voltage 208-230/460 60 Hz 3 Phase Max Operating Amps 3.8-3.5/1.7 Motor HP 1 Max BHP 1.17 RPM 1140 Max Inlet Temp 120 Degrees F Base Width 34 In. Base Length 34 In. Base Height 1-3/4 In. Base Top to Shroud 6-1/4 In. Overall Height 17-1/2 In. Overall Dia 42 In. Roof Mounting Location Housing Material Spun Aluminum

  • Gallery
  • Description
Exhaust Ventilator 24 In 208-230/460 V

Direct Drive Axial Exhaust Ventilator Propeller Dia 24 In. CFM @ 0.000-In. SP 6042 Sones @ 0.125-In. SP @ 5 ft 21 Sones @ 0.250-In. SP @ 5 ft 20 Voltage 208-230/460 60 Hz 3 Phase Max Operating Amps 3.8-3.5/1.7 Motor HP 1 Max BHP 1.17 RPM 1140 Max Inlet Temp 120 Degrees F Base Width 34 In. Base Length 34 In. Base Height 1-3/4 In. Base Top to Shroud 6-1/4 In. Overall Height 17-1/2 In. Overall Dia 42 In. Roof Mounting Location Housing Material Spun Aluminum
