AIR HANDLER

Pocket Air Filter Synthetic 20x24x30In. (5M414)

Sold out
  • Pocket Air Filter Synthetic 20x24x30In.

AIR HANDLER

Pocket Air Filter Synthetic 20x24x30In. (5M414)

Sold out
Mfr Model #:
Contract  51V : Catalog - 332510C

Pocket Air Filter Media Color Orange Filter Efficiency - Air Filters 65 Percent MERV 11 20x24x30 Nominal Filter Size Nominal Height 20 In. Nominal Width 24 In. Nominal Depth 30 In. Number of Pockets 6 Media Material Synthetic Capacity CFM 1250 Air Flow 500 fpm Initial Resistance 0.35 In.WC Final Resistance 1 In.WC Media Area 50 sq. ft. Frame Material 24 ga. Galvanized Steel Frame Size 13/16 In. Max Temp 190 Degrees F Material Synthetic Actual Depth 30 In.

  • Gallery
  • Description
Pocket Air Filter Synthetic 20x24x30In.

Pocket Air Filter Media Color Orange Filter Efficiency - Air Filters 65 Percent MERV 11 20x24x30 Nominal Filter Size Nominal Height 20 In. Nominal Width 24 In. Nominal Depth 30 In. Number of Pockets 6 Media Material Synthetic Capacity CFM 1250 Air Flow 500 fpm Initial Resistance 0.35 In.WC Final Resistance 1 In.WC Media Area 50 sq. ft. Frame Material 24 ga. Galvanized Steel Frame Size 13/16 In. Max Temp 190 Degrees F Material Synthetic Actual Depth 30 In.
