Handle: Wedge
Inlet Connection Entry: Bottom
Seal Material: Buna-N
Nominal Valve Size: 1/8 in
Stem Material: Nickel-Plated Brass
Handle Material: Composite
Maximum Pressure - Combustible Gas: Not Rated
Vented Ball Valve: Non-Vented
Body Material: Chrome-Plated Brass
Color - Valve Handle: Black
Flow Pattern: Double L Flow
Valve Construction: One-Piece
Seat Material: PTFE
Maximum Pressure - Operating: 290 psi
Connection Type: FNPT x FNPT x FNPT
Media Temp. Range: 0 Degrees F to 175 Degrees F
Coefficient of Volume (Cv): 1.64
Overall Length: 1.47 in
For Media: Water, Gas, Oil, Air
Valve Ways: 3-Way
Maximum Pressure - Steam: Not Rated
Ball Material: Chrome-Plated Brass
3-A Standard Compliance: Not Rated
Vacuum Service Rating: 28 in Hg
Ball Port Style: Full Port
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 1ZPK4 |
| BRAND | AIGNEP USA |
| CATEGORY | Plumbing |
| MPN | 86700-02 |
| UPC | |
| COUNTRY OF ORIGIN | IT |
