Check Mechanism: Ball
For Media: Water, Steam
Standards: CRN, NSF
Flow: 1.4 gpm
Silent Check: Standard
Maximum Pressure - Operating: 300 psi
Maximum Pressure - Steam: 15 psi
Seal Material: EPDM
Media Temp. Range: 0 Degrees F to 250 Degrees F
Mounting Orientation: Vertical, Horizontal
Seat Material: RPTFE
3-A Standard Compliance: Not Rated
Nominal Valve Size: 1/2 in
Check Mechanism Material: RPTFE
Connection Type: Press x Press
Body Material: Bronze
Coefficient of Volume (Cv): 1.4
NSF Certifications for Food and Drinking Water: NSF 61
Cracking Pressure: 0.5 psi
Valve Body Style: Inline
