Ball Port Style: Full Port
Nominal Valve Size: 3/4 in
Valve Construction: Two-Piece
Valve Ways: 2-Way
Handle: Lever
NSF Certifications for Food and Drinking Water: NSF 61
Media Temp. Range: -20 Degrees F to 450 Degrees F
Ball Material: Chrome-Plated Brass
Vacuum Service Rating: 29 in Hg
Seal Material: PTFE
Stem Material: PTFE
Seat Material: PTFE
Maximum Pressure - Operating: 600 psi
Color - Valve Handle: Yellow
Connection Type: FNPT x FNPT
Valve Body Style: Straight
Maximum Pressure - Steam: 150 psi
Body Material: Brass, Bronze
Overall Length: 2.67 in
3-A Standard Compliance: Not Rated
Handle Material: Zinc-Plated Steel, PVC
Coefficient of Volume (Cv): 36
Maximum Pressure - Combustible Gas: Not Rated
Standards: CRN, Material Quality C89836 (Lead-Free)
For Media: Water
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 48XH96 |
| BRAND | APOLLO |
| CATEGORY | Plumbing |
| MPN | 77CLF10401A |
| UPC | |
| COUNTRY OF ORIGIN | US |
