Apollo Manual 2-Way Ball Valve NPT Stainless Steel (7610227A)

Valve Body Style: Straight

Handle Material: Stainless Steel

3-A Standard Compliance: Not Rated

Standards: Material Quality CF8M (1.4408), CRN, American Iron and Steel (AIS), Buy American Act (BAA), Build America Buy America Act (BABA)

For Media: Water, Steam

Connection Type: FNPT x FNPT

Valve Ways: 2-Way

Ball Port Style: Standard Port

Seat Material: PTFE

Vacuum Service Rating: 29 in Hg

Stem Material: 316 Stainless Steel

Seal Material: PTFE

Body Material: Stainless Steel

Coefficient of Volume (Cv): 7.2

Overall Length: 2.05 in

Handle: Locking Lever

Maximum Pressure - Combustible Gas: Not Rated

Ball Material: 316 Stainless Steel

Nominal Valve Size: 3/8 in

Maximum Pressure - Steam: 150 psi

Media Temp. Range: -50 Degrees F to 450 Degrees F

Maximum Pressure - Operating: 2,000 psi

Valve Construction: Two-Piece

NSF Certifications for Food and Drinking Water: NSF 61

Color - Valve Handle: Yellow
