Point Type: Conventional
Flute Type: Spiral
Cutting Direction: Right Hand
Helix Type: Regular Spiral
Number of Flutes: 2
Drill Bit Point Angle: 118 Degrees
Finish/Coating: TiN
Coolant Fed: Non-Coolant Through
Material: High Speed Steel
Drill Bit Size: #64
List Number: 150-TN
Size Decimal Equivalent: 0.0360
Flute Length: 5/8 in
Measurement System: Wire
ISO Material Group: P, N, M, K
Standards: ANSI
Shank Diameter: 0.9 mm
Drill Length Class: Jobber-Length
Shank Type: Straight
Material Application: Brass, Copper, Steel, Bronze, Aluminum, Cast Iron, Stainless Steel
Overall Length: 1-1/2 in
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 434N22 |
| BRAND | CHICAGO-LATROBE |
| CATEGORY | Machining |
| MPN | 70164 |
| UPC | 662355701645 |
| COUNTRY OF ORIGIN | JP |
