Chicago-Latrobe Screw Machine Drill Bit, 1/16", HSS (48204)

Size Decimal Equivalent: 0.0625

Material Application: Tool and Die Steel, Brass, Copper, Steel, Bronze, Aluminum, Cast Iron, Stainless Steel

Drill Bit Point Angle: 135 Degrees

List Number: 159-TN

Standards: ANSI

Helix Type: Regular Spiral

Shank Diameter: 1/16 in

Measurement System: Fractional Inch

Point Type: Split

Flute Length: 5/8 in

Overall Length: 1-5/8 in

ISO Material Group: P, N, M, K

Drill Bit Size: 1/16 in

Material: High Speed Steel

Number of Flutes: 2

Coolant Fed: Non-Coolant Through

Cutting Direction: Right Hand

Drill Length Class: Screw-Machine Length

Shank Type: Straight

Finish/Coating: TiN

Flute Type: Spiral
