Ball Port Style: Full Port
Valve Ways: 2-Way
Voltage: 12 to 24V AC/DC
For Media: Compressed Air, Natural Gas, Oil
Maximum Pressure - Operating: 600 psi
Valve Construction: Two-Piece
Seat Material: RPTFE
IP Rating: IP66
Media Temp. Range: -20 Degrees F to 370 Degrees F
NEMA Enclosure Rating: 4, 4X
Nominal Valve Size: 1-1/4 in
Valve Body Style: Straight
Maximum Operating Pressure Differential: 300 psi
Standards: ANSI 372
Body Material: Brass
NSF Certifications for Food and Drinking Water: NSF 61
3-A Standard Compliance: Not Rated
Connection Type: FNPT x FNPT
Seal Material: FKM
Ball Material: Chrome-Plated Brass
Stem Material: Nickel-Plated Brass
Actuator Cycle Time - 90 Degrees: 6 sec
Coefficient of Volume (Cv): 77
Fail Safe Position: Fail Last
Actuator Features: Position Indicator, Thermal Overload Protection, Heater
Maximum Pressure - Steam: 150 psi
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 1AWD7 |
| BRAND | DYNAQUIP CONTROLS |
| CATEGORY | Plumbing |
| MPN | EHH26ATE25H |
| UPC | |
| COUNTRY OF ORIGIN | US |
