Flow Rate @ 30 psi: 68 gpm
Motor Design: Capacitor-Start
Discharge: 1-1/4 in FNPT
NSF Certifications for Food and Drinking Water: NSF 372
Flow Rate @ 40 psi: 27 gpm
Manufacturer Warranty Length: 1 yr
For Water System Type: Non-Potable Water
Motor Frame Designation: 56J
Media Temp. Range: 34 Degrees F to 200 Degrees F
Best Efficiency Head: 62 ft
Flow Rate @ 20 psi: 88 gpm
Feet of Head - Maximum: 99 ft
Suction Lift - Maximum: 25 ft
Mounting Orientation: Horizontal
Phase: Single
Series: CJ
Number of Stages: 1
Shut Off Pressure - Maximum: 43 psi
Thermal Protection: Auto
Pressure Boost - Maximum: 45 psi
Flow Rate - Maximum: 80 gpm
Pump Casing Material: Cast Iron
Nameplate Voltage: 230V AC
Best Efficiency Flow: 70 gpm
Horsepower: 1-1/2 hp
Nominal Voltage: 240V AC
Standards: CSAus Listed
Case Pressure - Maximum: 100 psi
Motor Enclosure Design: Open Drip Proof
Electrical Connection Type: Hardwired
Inlet: 1-1/2 in FNPT
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 22W744 |
| BRAND | FLINT & WALLING |
| CATEGORY | Pumps |
| MPN | CJ103151 |
| UPC | |
| COUNTRY OF ORIGIN | US |
