Flow Rate @ 30 psi: 48 gpm
Number of Stages: 2
Phase: Three
Best Efficiency Flow: 37 gpm
Flow Rate @ 40 psi: 42 gpm
Flow Rate @ 60 psi: 27 gpm
Suction Lift - Maximum: 25 ft
Series: CJ
Motor Design: Capacitor-Start
Electrical Connection Type: Hardwired
Horsepower: 2 hp
Media Temp. Range: 34 Degrees F to 200 Degrees F
Motor Frame Designation: 56J
Manufacturer Warranty Length: 1 yr
Pump Casing Material: Cast Iron
Feet of Head - Maximum: 165 ft
Flow Rate @ 50 psi: 35 gpm
Nameplate Voltage: 208-230/460V AC
Inlet: 1-1/2 in FNPT
Mounting Orientation: Horizontal
Flow Rate - Maximum: 51 gpm
Best Efficiency Head: 115 ft
For Water System Type: Non-Potable Water
Discharge: 1-1/4 in FNPT
Flow Rate @ 20 psi: 50 gpm
NSF Certifications for Food and Drinking Water: NSF 372
Standards: CSAus Listed
Pressure Boost - Maximum: 95 psi
Motor Enclosure Design: Open Drip Proof
Thermal Protection: Auto
Case Pressure - Maximum: 160 psi
Nominal Voltage: 208-240/480V AC
Shut Off Pressure - Maximum: 70 psi
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 22W759 |
| BRAND | FLINT & WALLING |
| CATEGORY | Pumps |
| MPN | CJ101B203AB |
| UPC | |
| COUNTRY OF ORIGIN | US |
