Case Pressure - Maximum: 300 psi
Nominal Voltage: 208-240/480V AC
Best Efficiency Flow: 7 gpm
Discharge: 3/4 in FNPT
Flow Rate @ 20 psi: 13.4 gpm
Flow Rate @ 60 psi: 10.9 gpm
Pressure Boost - Maximum: 216 psi
Media Temp. Range: 34 Degrees F to 140 Degrees F
Nameplate Voltage: 208-230/460V AC
Flow Rate @ 50 psi: 11.5 gpm
Suction Lift - Maximum: 0 ft
Flow Rate @ 30 psi: 12.9 gpm
Motor Enclosure Design: Open Drip Proof
Pump Casing Material: Cast Iron
Flow Rate @ 40 psi: 12.2 gpm
Phase: Three
Feet of Head - Maximum: 380 ft
Flow Rate @ 70 psi: 10.2 gpm
Number of Stages: 12
Series: PB
Manufacturer Warranty Length: 1 yr
NSF Certifications for Food and Drinking Water: NSF 372
Shut Off Pressure - Maximum: 152 psi
Best Efficiency Head: 282 ft
Electrical Connection Type: Hardwired
For Water System Type: Non-Potable Water
Standards: CSAus Certified
Flow Rate @ 80 psi: 9.5 gpm
Motor Frame Designation: 56J
Mounting Orientation: Horizontal
Motor Design: Capacitor-Start
Flow Rate - Maximum: 42 gpm
Horsepower: 3/4 hp
Inlet: 3/4 in FNPT
Thermal Protection: Auto
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 22W712 |
| BRAND | FLINT & WALLING |
| CATEGORY | Pumps |
| MPN | PB0712A073 |
| UPC | |
| COUNTRY OF ORIGIN | US |
