- Nominal Valve Size: 1 in
- Maximum Pressure Combustible Gas: Not Rated
- Handle: Locking Lever
- Valve Body Style: Straight
- 3 A Standard Compliance: Not Rated
- Vented Ball Valve: Non-Vented
- Body Material: Carbon Steel
- Maximum Pressure Steam: 200 psi
- Handle Material: Stainless Steel
- Color Valve Handle: Red
- Maximum Pressure Operating: 285 psi
- Stem Material: 316 Stainless Steel
- Coefficient Of Volume (Cv): 42
- Vacuum Service Rating: -29.912 in Hg
- Valve Construction: One-Piece
- Standards: NACE MR0175, API 607, API 608, ASME B16.34
- Media Temp. Range: -20 Degrees F to 500 Degrees F
- Ansi Flange Class: Class 150
- Connection Type: Class 150 Flange
- Ball Port Style: Standard Port
- Seat Material: PTFE
- Seal Material: Graphite
- Ball Material: 316 Stainless Steel
- Valve Ways: 2-Way
- For Media: Combustible Gases
- Overall Length: 5 in
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 45AL94 |
| BRAND | KECKLEY |
| CATEGORY | Plumbing |
| MPN | BVF1RF2RCSRGSL-100 |
| UPC | |
| COUNTRY OF ORIGIN | TW |
