Ball Port Style: Full Port
3-A Standard Compliance: Not Rated
Body Material: Carbon Steel
Maximum Pressure - Steam: 200 psi
ANSI Flange Class: Class 150
Valve Construction: Two-Piece
Vented Ball Valve: Non-Vented
Valve Ways: 2-Way
Vacuum Service Rating: -29.912 in Hg
Stem Material: 316 Stainless Steel
Handle: Locking Lever
Maximum Pressure - Combustible Gas: Not Rated
Seat Material: PTFE
For Media: Combustible Gases
Ball Material: 316 Stainless Steel
Valve Body Style: Straight
Standards: NACE MR0175, API 607, API 608, ASME B16.34
Seal Material: Graphite
Connection Type: Class 150 Flange
Maximum Pressure - Operating: 285 psi
Handle Material: Stainless Steel
Color - Valve Handle: Red
Media Temp. Range: -20 Degrees F to 500 Degrees F
Nominal Valve Size: 2-1/2 in
Overall Length: 7.5 in
Coefficient of Volume (Cv): 550
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 52RV68 |
| BRAND | KECKLEY |
| CATEGORY | Plumbing |
| MPN | BVF2RF2FCSRGSL-250 |
| UPC | |
| COUNTRY OF ORIGIN | TW |
