Leeson Hazardouslocationmotor, 1Hp, 1765Rpm (143TTGN16539)

Frame: 143TC

Motor Service Factor: 1.15

Motor Application: Hazardous Location

Motor Thermal Protection: T-Stat

Phase: Three

Full Load Amps: 3.3/1.7 A

Hz: 60 Hz

Motor Shaft Rotation: CW/CCW

Hazardous Location Class: Class I, Class II

Motor Design: Three-Phase

Ins. Class: B

Hazardous Location Division: Division I

Motor Enclosure Design: Totally Enclosed Fan Cooled

Usable @ 208V: Not Usable at 208V, No

HP: 1 hp

Voltage: 230V AC, 460V AC

Motor Mounting Type: C-Face

No. of Speeds: 1

Voltage Compatibility: 230/460V AC, 208-230/460V AC, 208-220/440V AC, 200-230/460V AC, 200-230/440V AC

Nominal Voltage: 230V AC, 460V AC

RPM Range: 1,701-1,800, 1,400 - 1,800

Hazardous Location Group: Group G, Group F, Group D

Manufacturer Part Number: 143TTGN16539
