Valve Body Style: Straight
Standards: MSS SP-110
Ball Material: Chrome-Plated Brass
Valve Ways: 2-Way
Maximum Pressure - Steam: 600 psi
Overall Length: 2 in
Body Material: Bronze
Stem Material: Silicon Bronze
Maximum Pressure - Operating: 600 psi
Valve Construction: Two-Piece
Color - Valve Handle: Blue
Handle Material: Zinc-Plated Steel
Handle: Lever
Seat Material: PTFE
Media Temp. Range: -20 Degrees F to 400 Degrees F
Connection Type: FNPT x FNPT
For Media: Water, Steam, Air
Maximum Pressure - Combustible Gas: Not Rated
3-A Standard Compliance: Not Rated
Nominal Valve Size: 3/8 in
Ball Port Style: Full Port
Seal Material: PTFE
