- Operating Pressure Differential Steam Maximum: 125 psi
- Valve Type: Diaphragm and Piston
- Coefficient Of Volume (Cv): 2.1 - 5.0, 4.7
- Valve Ways: 2-Way
- Coil Enclosure: Watertight, Without Junction Box
- Valve Starting Configuration: Normally Closed
- Ambient Temperature Maximum: 140 Degrees F
- Fluid Temperature Maximum: 353 Degrees F
- Body Material: Brass
- Operating Pressure Differential Minimum: 5 psi
- Ambient Temperature Minimum: 14 Degrees F
- Operation Type: Pilot Operated
- Operating Pressure Differential Hot Water Maximum: 150 psi
- Seal Material: EPDM, EPDM/PTFE
- Coil Insulation Class: H
- Voltage: 120V AC, 110V AC
- Orifice Diameter: 1/2 in
- Environmental Rating: Washdown, Hazardous, Outdoor, Indoor
- For Media: Steam, Hot Water
- Nominal Pipe Size: 1/2 in
- Standards: UL Listed, CSA
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 4NWZ5 |
| BRAND | REDHAT |
| CATEGORY | Plumbing |
| MPN | 8220G406 |
| UPC | |
| COUNTRY OF ORIGIN | MX |
