For Media: Steam, Hot Water
Ambient Temperature - Minimum: 14 Degrees F
Operation Type: Pilot Operated
Valve Ways: 2-Way
Nominal Pipe Size: 3/4 in
Orifice Diameter: 3/4 in
Coefficient of Volume (Cv): 5.1 - 10.0, 8.8
Ambient Temperature - Maximum: 140 Degrees F
Body Material: Brass
Coil Insulation Class: H
Valve Starting Configuration: Normally Closed
Voltage: 24/60V AC
Fluid Temperature - Maximum: 353 Degrees F
Operating Pressure Differential Steam - Maximum: 125 psi
Operating Pressure Differential Hot Water - Maximum: 150 psi
Seal Material: EPDM, EPDM/PTFE
Coil Enclosure: Watertight, Without Junction Box
Environmental Rating: Washdown, Hazardous, Outdoor, Indoor
Operating Pressure Differential - Minimum: 5 psi
Standards: UL Listed, CSA
Valve Type: Diaphragm and Piston
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 6WTV9 |
| BRAND | REDHAT |
| CATEGORY | Plumbing |
| MPN | 8220G409 |
| UPC | |
| COUNTRY OF ORIGIN | MX |
