- Handle: Lever
- Valve Body Style: Straight
- Overall Length: 3.14 in
- Body Material: Bronze
- Vacuum Service Rating: -29.2 in Hg
- For Media: Potable Water
- Seal Material: EPDM
- Standards: FM Listed, IAPMO: Uniform Plumbing Code, CRN, 13D and 13R: Fire Sprinkler, NSF/ANSI 372: Drinking Water System Components - Lead Content, NFPA 13, PHCC: National Standard Plumbing Code, ICC, UL Listed, CSA
- Vented Ball Valve: Non-Vented
- Maximum Pressure Steam: Not Rated
- Valve Ways: 2-Way
- Valve Construction: Two-Piece
- Ball Port Style: Full Port
- Stem Material: Brass
- Maximum Pressure Combustible Gas: Not Rated
- Handle Material: Metal
- Nsf Certifications For Food And Drinking Water: NSF 61
- Color Valve Handle: Green
- Connection Type: Press x Press
- Maximum Pressure Operating: 200 psi
- 3 A Standard Compliance: Not Rated
- Ball Material: Stainless Steel
- Seat Material: PTFE
- Media Temp. Range: 0 Degrees F to 250 Degrees F
- Nominal Valve Size: 1/2 in
About the Item
| Specification Name | Specification Value |
|---|---|
| SKU | 20XW46 |
| BRAND | VIEGA PROPRESS |
| CATEGORY | Plumbing |
| MPN | 79920 |
| UPC | |
| COUNTRY OF ORIGIN | DE |
