Connection Type: Flange
Shut-Off Valve Included: OSY Gate Valve
Configuration: with Flood Detection Sensor
Mounting Orientation: Horizontal
Body Material: 304 Stainless Steel
Media Temp. Range: 33 Degrees F - 140 Degrees F
Valve Series: 957
Seat Material: Plastic
Overall Length: 31.75 in
For Media: Water
Max. Pressure (CWP): 175 psi
Pipe Size: 3 in
Standards: CSA B64.4, ASSE 1013, AWWA C511-97, FM, NSF, cULus Classified, FCCCHR-USC
Overall Height: 25.56 in
Overall Width: 10.5 in
